Description
Super Resolution Reality Creation
The VPL-VW790ES analyses every pixel of every image and then employs pattern-matching algorithms developed over years of movie production to enhance crispness without increasing digital picture noise.
Digital Focus Optimiser
Again, each pixel of each image is analysed using our own advanced algorithm to perform optimum image quality correction so that image focus is better than ever, even in the corners.
Specifications
Display System
Display System4K SXRD panel, projection system
Display device
Size of effective display area0.74” x 3
Number of pixels26,542,080 (4096 x 2160 x 3) pixels
Projection lens
FocusPowered
ZoomPowered (Approx. x2.06)
Lens shiftPowered
Vertical: +85% -80% Horizontal: +/-31%
Throw ratio*11:38 : 1 to 2:83 : 1
Light source
Light sourceLaser diode
Screen size
Screen size60” to 300” (1,524 mm to 7,620 mm)
Light output
Light output2,000 lm
Colour light output
Colour light output2,000 lm
Dynamic contrast
Dynamic contrast∞:1
Displayable scanning frequency
Horizontal19 kHz to 72 kHz
Vertical48 Hz to 92 Hz
Accepted digital signals
Accepted digital signals720 x 576/50p, 720 x 480/60p, 1280 x 720/50p, 1280 x 720/60p, 1920 x 1080/50i, 1920 x 1080/60i, 1920 x 1080/24p, 1920 x 1080/50p, 1920 x 1080/60p, 3840 x 2160/24p, 3840 x 2160/25p, 3840 x 2160/30p, 3840 x 2160/50p, 3840 x 2160/60p, 4096 x 2160/24p, 4096 x 2160/25p, 4096 x 2160/30p, 4096 x 2160/50p, 4096 x 2160/60p
OSD language
OSD language18-languages (English, Dutch, French, Italian, German, Spanish, Portuguese, Turkish, Polish, Russian, Swedish, Norwegian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Thai, Arabic)
INPUT OUTPUT (Computer / Video / Control)
HDMI1 / HDMI2 *2Digital (RGB/Y Pb/Cb Pr/Cr)
TriggerMinijack, DC 12 V Max. 100 mA
RemoteRS-232C, D-sub 9-pin (male)
LANRJ45, 10Base-T/100BASE-TX
IR INMini Jack
USBDC 5 V, Max. 500 mA
Picture processor
Picture processorX1 for projector
Acoustic noise
Acoustic noise24 dB *3
Operating temperature / Operating humidity
Operating temperature / Operating humidity5°C to 35°C (41°F to 95°F) / 35% to 85% (no condensation)
Storage temperature / Storage humidity
Storage temperature / Storage humidity-20°C to +60°C (-4°F to +140°F) / 10% to 90% (no condensation)
Power requirements
Power requirementsAC 100 V to 240 V, 4.3 A to 1.8 A, 50/60Hz
Power consumption
Power consumption430 W
Standby0.4 W (when “Remote Start” is set to “Off”)
Networked Standby1.0W (LAN) (when “Remote Start” is set to “On”)
When a LAN terminal is not connected, it becomes a low power consumption mode (0.5 W).
Standby Mode / Networked Standby Mode Activated
Standby Mode / Networked Standby Mode ActivatedAfter about 10 Minutes
3D
3D capabilityYes
3D emitterBuilt-in RF emitter
Dimensions (W x H x D) (without protrusions)
Dimensions (W x H x D) (without protrusions)560 x 223 x 496 mm
22 1/16 x 8 25/32 x 19 17/32 inches
Mass
MassApprox. 20 kg / 44 lb
Supplied accessories
Supplied accessoriesRM-PJ24 Remote Commander (1)
Size AA (R6) Manganese Batteries (2)
Lens Cap (1)
AC Power Cord (1)
Operating Instructions (CD-ROM) (1)
Quick Reference Manual (1)
Safety Regulations (1)
