JBL CSS-H30 30 Watt Paging Horn
JBL CSS-H30 30 Watt Paging Horn
JBL CSS-H30 30 Watt Paging Horn
JBL CSS-H30 30 Watt Paging Horn

JBL CSS-H30 30 Watt Paging Horn

Rs. 16,520.00

Key Features

Excellent voice range clarity for announcement and paging.

High sensitivity delivers high sound levels with minimal power amplification.

Focused 50° horizontal by 70° vertical coverage for long throw capability.

Phenolic diaphragm driver for outdoor durability and high reliability.

UL-registered 30-watt multi-tap transformer, with 8 ohm direct bypass.

Built-in high-pass filter enhances reliability by protecting against low frequency damage.

Highly weather-resistant, with stainless steel bracket and hardware.

Standard warranty provide by OEM

Share

Facebook X (Twitter) Pinterest
Rs. 16,520.00
JBL CSS-H30 30 Watt Paging Horn
Rs. 16,520.00

Product Description

30 Watt Paging Horn

The Commercial Solutions Series CSS-H30 Paging Horn provides excellent voice range clarity for public address systems, announcement/paging, intercom, security, alarm and industrial applications. Designed for demanding environmental conditions, the CSS-H30 is highly weather resistant (IP-65 rated) so it can be used in either indoor or outdoor applications. The focused coverage pattern allows the horn to project the sound a farther distance than is the case with wider-coverage paging horns. Typical applications for this product are public access areas, warehouses, factories, schools, recreational facilities, commercial buildings, distribution centers, civic centers, and other commercial sound and protectivesignaling systems.

Specification

Brand JBL Professional
Model CSS-H30
Speaker Type 30 W Paging Horn
Frequency Range (-10 dB) 380 Hz – 6 kHz
Coverage 50° H × 70° V
Power Rating 30 W Continuous Pink Noise / 120 W Peak
Sensitivity 108 dB, 1 W / 2.83 V @ 1 m; 112 dB @ 1.4 kHz
Maximum SPL 123 dB continuous / 129 dB peak; 127 dB continuous / 133 dB peak @ 1.4 kHz
Directivity Factor (Q) 15.8 @ 2 kHz
Directivity Index (DI) 12 dB @ 2 kHz
Nominal Impedance 8 Ω direct
Transformer Taps – 70V 30 / 15 / 7.5 / 3.8 / 1.9 W
Transformer Taps – 100V 30 / 15 / 7.5 / 3.8 W
Driver 38 mm (1.5") phenolic diaphragm
High-Pass Filter Built-in passive 350 Hz
Horn Material ABS
Mounting Hardware Stainless-steel powder-coated U-bracket
Environmental Rating IP65
Salt Spray Protection B117 compliant
Input Connection 300 mm pigtail cable to bare wire
Color RAL9016 White
Dimensions – Horn 206 × 285 × 287 mm
Dimensions with Bracket 224 × 285 × 287 mm
Net Weight 2.0 kg
Shipping Weight 2.7 kg
Included Accessory Stainless-steel mounting bracket
