Electro-Voice ETX-35P 35" inches Powered Loudspeaker
Key Features
Product Description
The Electro-Voice ETX-35P is a professional 15-inch powered 3-way loudspeaker designed for high-output live sound, touring, entertainment venues, and demanding professional PA applications. It combines a 15-inch SMX LF woofer, 6.5-inch EVS-6C mid-bass driver, and 1.25-inch DH3-B titanium compression driver, powered by a 2000 W Class-D amplifier with integrated FIR-Drive DSP.
With a 136 dB peak SPL and 48 Hz–20 kHz (-3 dB) frequency response, the ETX-35P delivers powerful low frequencies, clear midrange reproduction, and detailed high-frequency performance. Its 60° × 40° coverage provides controlled sound distribution for professional applications.
The speaker features a rugged 18 mm plywood enclosure with EVCoat, 16 AWG powder-coated steel grille, and eight M10 suspension points for permanent installation. It also includes dual XLR/TRS combo inputs and an XLR link output for flexible professional connectivity.
Specifications
| Details | |
|---|---|
| Product Type | Powered 3-Way Loudspeaker |
| Power Rating | 2000 W |
| Frequency Response (-3 dB) | 48 Hz – 20 kHz |
| Frequency Range (-10 dB) | 38 Hz – 20 kHz |
| Maximum SPL | 136 dB Peak |
| Coverage (H × V) | 60° × 40° |
| LF Transducer | SMX2151 15" (380 mm) |
| MB Transducer | EVS-6C 6.5" Mid-Bass Driver |
| HF Transducer | DH3-B 1.25" Titanium Compression Driver |
| Crossover Frequencies | 700 Hz, 2.9 kHz |
| Connectors | 2 × XLR/TRS Combo, 1 × XLR Link Output |
| Enclosure Material | 18 mm Plywood with EVCoat |
| Grille | 16 AWG Powder-Coated Steel |
| Suspension Points | 8 × M10 |
| Dimensions (H × W × D) | 1023 × 469 × 426 mm |
| Net Weight | 38.2 kg |
| Shipping Weight | 42.8 kg |
| Power Requirement | 100–240 V AC, 50–60 Hz, 1.6–0.8 A |
