Bose Professional Veritas 2160BH Smart Mixer Amplifier
Key Features
Product Description
The award-winning Veritas series from Bose Professional delivers superior background/foreground music, paging and multimedia for commercial applications. Bluetooth® 5.0 wireless input and user-intuitive OLED screen with quick-start QR code simplify setup—whether you’re a pro installer or a DIYer. With four models to choose from, Veritas amplifiers offer the perfect combination of power, performance and flexibility.
The ultimate choice for large-scale 70V/100V distributed audio systems, the 2160BH efficiently powers multiple zones with premium sound clarity and reliable, consistent coverage. Ideal for hotels, conference centers, and multi-room installations, the 2160BH offers high output with advanced features for integrators handling complex, high-demand applications.
Specification
| Brand | Bose Professional |
| Model | Veritas 2160BH |
| Product Type | Smart Mixer Amplifier |
| Amplifier Type | High-Impedance |
| Supported System | 70V / 100V |
| Rated Power | 2 × 160W @ 70V / 100V |
| Frequency Response | 20Hz – 20kHz (+0/-3dB) |
| THD+N | ≤0.5% @ Rated Power |
| Dynamic Range | 88dB |
| Channel Separation | ≤ -58dBu @ 1kHz |
| Analog Inputs | 2 × Balanced Line, 2 × Unbalanced Line, 1 × Balanced Mic/Line |
| Input Connectors | 2 × RCA Stereo Pairs, 2 × 5-Pin Euroblock, 1 × 4-Pin Euroblock |
| Input Impedance | 20kΩ Line / 2kΩ Paging |
| Input Range | -8dBu to +22dBu Line / -58dBu to +12dBu Paging |
| Maximum Input Level | +22dBu Line / +12dBu Paging |
| Analog Outputs | 2 × Loudspeaker + 1 × Unbalanced Line |
| Speaker Outputs | 2 × 2-Pin Inverted Euroblock |
| Aux Output | 1 × RCA Stereo Pair |
| Speaker Output | 2 × 160W @ 70V / 100V |
| Bluetooth | Bluetooth 5.0 |
| DSP | 24-bit / 48kHz |
| Audio Latency | 10.4ms |
| DSP Functions | Loudspeaker EQ, Opti-Voice Paging, Dynamic EQ |
| EQ Presets | Up to 30 Selectable Presets |
| Speaker Presets | 70Hz HPF, 80Hz HPF, AMU105, AMU108, DesignMax, EdgeMax, FreeSpace FS, Subwoofer |
| Front Controls | Power, Input Select, Rotary Encoder |
| Rear Controls | Amplifier Mode DIP Switches, Input Gain, Page Threshold, Mute, ControlCenter Ports |
| Remote Control | Bose Professional / Third-Party Wall Controllers |
| Control Ports | 2 × ControlCenter Ports |
| Cooling | Fan Cooling, Left-to-Right Airflow |
| Power Supply | 100–240VAC ±10%, 50/60Hz |
| Power Consumption | 13.6W Standby / 500W Maximum |
| Protection | High Temperature, Output Short Circuit, AC Line Voltage Protection |
| Dimensions (H × W × D) | 44 × 483 × 324mm |
| Rack Size | 1RU |
| Net Weight | 4.4kg |
| Shipping Weight | 5.8kg |
