Bose Professional Veritas 1100BH Smart Mixer Amplifier
Key Features
Product Description
The award-winning Veritas series from Bose Professional delivers superior background/foreground music, paging and multimedia for commercial applications. Bluetooth® 5.0 wireless input and user-intuitive OLED screen with quick-start QR code simplify setup—whether you’re a pro installer or a DIYer. With four models to choose from, Veritas amplifiers offer the perfect combination of power, performance and flexibility.
Compact and powerful, the 1100BH is suited for smaller distributed audio systems, background music, and paging applications. Designed for 70V/100V high-impedance systems, it efficiently powers multiple wall or ceiling loudspeakers to deliver broad coverage. Perfect for smaller venues, offices, and retail spaces, the 1100BH features a smaller half-rack size and front XLR/¼-inch input for convenient mic or audio source connection.
Specification
| Brand | Bose Professional |
| Model | Veritas 1100BH |
| Product Type | Smart Mixer Amplifier |
| Amplifier Power | 1 × 100W @ 70V / 100V |
| System Type | High-Impedance 70V / 100V |
| Frequency Response | 70Hz – 18kHz (+0/-4dB) |
| THD+N | ≤0.3% |
| Dynamic Range | 88dB |
| Analog Inputs | 2 × Unbalanced Line + 2 × Balanced Mic/Line |
| Input Connectors | 2 × RCA Stereo Pairs, 1 × XLR/¼", 1 × 4-Pin Euroblock |
| Input Impedance | 20kΩ Line / 2.4kΩ Paging |
| Maximum Input Level | +10dBV |
| Speaker Output | 1 × 100W @ 70V / 100V |
| Speaker Connector | 1 × 3-Pin Inverted Euroblock |
| Aux Output | 1 × Unbalanced Line, RCA Stereo Pair |
| Bluetooth | Bluetooth 5.0 |
| DSP | 24-bit / 48kHz |
| DSP Functions | Loudspeaker EQ, Dynamic EQ, Opti-Voice Paging, Volume & Tone Control |
| EQ Presets | Up to 30 selectable presets |
| Speaker Presets | AMU105, AMU108, DesignMax, EdgeMax, FreeSpace FS, Subwoofer, 70/80Hz HPF |
| Audio Latency | 10.4ms |
| Display | Front OLED Display |
| Controls | Power, Input Select, Input Gain, Rotary Encoder |
| Remote Control | Bose Professional / Third-Party Wall Controllers |
| Control Port | ControlCenter Port |
| Cooling | Natural Convection / Fanless |
| Power Supply | 100–240VAC ±10%, 50/60Hz |
| Power Consumption | 15W Idle / 200W Maximum |
| Protection | High Temperature & Output Short Circuit |
| Dimensions (H × W × D) | 44 × 214 × 310mm |
| Rack Size | 1RU × ½ Rack Width |
| Net Weight | 3.2kg |
