Product Description
Put the power where you need it. PowerShare amplifiers deliver outstanding audio performance and reliability with patented technologies inherited from the field-proven Bose Professional PowerMatch line — now with added flexibility. Using innovative PowerShare technology, the amp shares power across all output channels and delivers 600 watts for installed applications. This means you can distribute the total 600 watts asymmetrically across all outputs or use any individual output to deliver full power. And with support for both low- and high-impedance loads up to 100V, it’s easy to adapt PowerShare amplifiers to a wide range of applications. ControlSpace Designer software allows for Ethernet-based configuration and quick setup of external control options. With onboard Dante® audio networking, you have the flexibility to place PowerShare amplifiers away from source locations and closer to loudspeakers. This unique set of features and technologies makes PowerShare one of the most versatile, high-performance amplifiers available today.
Specification
| Brand | Bose Professional |
| Model | PowerShare PS604D |
| Product Type | Adaptable Power Amplifier |
| Amplifier Type | c PowerShare Networked DSP Amplifier |
| Number of Channels | 4 |
| Rated Power – Symmetrical | 4 × 150W |
| Rated Power – Asymmetrical | 600W Total |
| Maximum Power per Channel | Up to 600W |
| Low-Impedance Load | 4–8Ω |
| High-Impedance Load | 70V / 100V |
| Power Sharing | Asymmetrical across all outputs |
| Maximum Peak Power – Symmetrical | 300W |
| Maximum Peak Power – Asymmetrical | 1200W |
| Frequency Response | 20Hz–20kHz ±0.5dB @ 1W |
| THD+N | <0.04% @ 1kHz |
| Dynamic Range | 100dB, A-weighted |
| Signal-to-Noise Ratio | 100dB, A-weighted |
| Channel Separation | >85dB @ 1kHz / >65dB @ 20kHz |
| Low-Z Gain | 32dB |
| 70V Gain | 35dB |
| 100V Gain | 38dB |
| Analog Inputs | 4 × Balanced Line |
| Analog Input Connector | 12-Pin Euroblock |
| Input Impedance | 20kΩ |
| Maximum Input Level | 20dBu |
| Input Sensitivity | 4dBu Low / 12dBu High |
| Dante Inputs | 4 Digital Channels |
| Dante Connectors | 2 × RJ-45 Dante In/Thru |
| Analog Outputs | 4 Channels |
| Output Connector | 8-Pin Inverted Euroblock |
| Dante Networking | Integrated Dante Audio Networking |
| DSP | 24-bit / 48kHz |
| DSP Functions | Matrix Mixer, Loudspeaker EQ, 9-Band PEQ, Limiters, Delay, Band-Pass, Mute, Output Polarity Inversion |
| Crossover | Butterworth, Bessel & Linkwitz-Riley up to 48dB/octave |
| Audio Latency | <1ms Analog Input to Analog Output |
| Output Delay | Up to 50ms on Outputs 3–4 |
| Loudspeaker Presets | Bose Professional Loudspeaker Presets |
| Control Software | ControlSpace Designer 5.4 or later |
| Network Interface | RJ-45 Ethernet, 100Mbps |
| Auto-Standby | Yes |
| Front Control | Power On/Off |
| Rear Controls | Output Attenuators, Mute Contact |
| Cooling | Microprocessor-Controlled Variable-Speed Fans |
| Airflow | Left-to-Right |
| Power Supply | 100–240VAC ±10%, 50/60Hz |
| Power Consumption | 14W Standby / 700W Maximum |
| Mains Connector | IEC C14 |
| Protection | High Temperature, Output Short Circuit, EHF, Low/High AC Voltage |
| Mounting | Rack Mount |
| Rack Space | 1RU |
| Dimensions (H × W × D) | 44 × 483 × 414mm |
| Net Weight | 6.4kg |
| Shipping Weight | 7.8kg |
| Colour | Black |
