Bose EdgeMax EM90 In-Ceiling Directional Loudspeaker
Bose EdgeMax EM90 In-Ceiling Directional Loudspeaker
Bose EdgeMax EM90 In-Ceiling Directional Loudspeaker
Bose EdgeMax EM90 In-Ceiling Directional Loudspeaker
Bose EdgeMax EM90 In-Ceiling Directional Loudspeaker
Bose EdgeMax EM90 In-Ceiling Directional Loudspeaker

Bose EdgeMax EM90 In-Ceiling Directional Loudspeaker

Rs. 182,334.00

Key Features

Patented PhaseGuide technology evenly distributes sound throughout the space to ensure all listeners enjoy the same experience—regardless of their location

High-frequency compression driver and high-excursion woofer for exceptional audio quality and power

In-ceiling installation for minimum visual impact, with fewer units required to deliver uniform sound

In-ceiling mounting near room edges and corners (75° vertical coverage and 90° horizontal coverage)

Wall-boundary loading for greater bass response and performance

2-way passive crossover with bypassable 70/100V transformer

Consistent voicing across the EdgeMax family

QuickHold spring-loaded mounting system for easy installs

Magnetically attached grille for quick access to wiring and tap settings

UL 1480A and UL 2043 safety standard compliance

Standard warranty provide by OEM

Share

Facebook X (Twitter) Pinterest
Rs. 182,334.00
Bose EdgeMax EM90 In-Ceiling Directional Loudspeaker
Rs. 182,334.00

Product Description

Bose Professional’s EdgeMax series combines the performance of big, bulky surface-mount loudspeakers with stealthy design to shatter the limitations of traditional in-ceiling loudspeakers. Dual drivers and patented PhaseGuide® technology allow EdgeMax loudspeakers to project powerful, focused sound from the room’s edges to the center. They deliver amazing directionality and voice intelligibility to ensure all listeners enjoy the same sound—regardless of their location. Larger rooms with higher SPL needs, such as fitness centers, benefit from the powerful, deeper 9-inch (24 cm) cans of EdgeMax EM. In these demanding environments, EM models deliver proven performance, with immersive full-frequency sound for music and clear intelligibility for voice, even at high volumes. Also, EM models are designed with 75-degree vertical coverage, optimal for rooms with higher ceilings.

Specifications

Brand Bose Professional
Model EdgeMax EM90
Product Type In-Ceiling Directional Loudspeaker
Configuration 2-Way Passive
Low-Frequency Driver 1 × 8" (203 mm) Woofer, 1.5" Voice Coil
High-Frequency Driver 1 × Compression Driver, 1.3" (33 mm) Voice Coil
Frequency Range (-10 dB) 45 Hz – 20 kHz
Frequency Response (-3 dB) 50 Hz – 18 kHz
Coverage – Horizontal 90°
Coverage – Vertical 75° Asymmetrical
Maximum SPL @ 1 m 117 dB Continuous / 123 dB Peak
Nominal Impedance 8 Ω (Transformer Bypassed)
Power Handling – Continuous 125 W
Power Handling – Peak 500 W
Sensitivity 96 dB SPL (1 W / 1 m)
Crossover 1 kHz Passive 2-Way
Transformer Taps – 70V 2.5 / 5 / 10 / 20 / 40 / 80 W / Bypass
Transformer Taps – 100V 5 / 10 / 20 / 40 / 80 W / Bypass
High-Pass Protection 55 Hz, Minimum 12 dB/Octave
Enclosure Material Engineered-Plastic Front Baffle with Integrated Steel Enclosure
Grille Micro-Perforated Steel, Powder-Coated, Paintable
Colour White, Similar to RAL 9003
Environmental Indoor Only
Safety Compliance UL 1480A, UL 2043
Operating Temperature 0°C – 50°C
Mounting 4 QuickHold Spring-Loaded Mounting Arms + 4 M6 Safety Cable Points
Maximum Ceiling Thickness 80 mm
Ceiling Cutout 345 × 345 mm
Mounting Depth 236 mm
Speaker Dimensions 339 × 339 × 249 mm
Grille Flange Dimensions 390 × 390 × 13 mm
Net Weight 10.1 kg
Shipping Weight 12.5 kg
Connector 6-Pin Euroblock with Loop-Through
