Bosch PLE-1ME060-4IN – 60W Mixer Amplifier with USB/Bluetooth
Key Features
Product Description
The Bosch PLE-1ME060-4IN is a 60 W Class-D mixer amplifier designed for professional public address (PA) and background music applications. It combines a high-efficiency amplifier with built-in Bluetooth audio streaming, USB media playback, and FM radio, providing an all-in-one audio solution for commercial installations.
The amplifier features 4 microphone/line inputs and 1 dedicated BGM/AUX input, allowing multiple audio sources to be connected simultaneously. It supports 100 V line and 4 Ω speaker outputs, along with a dedicated 100 V call-only output for priority announcements. Additional features include switchable phantom power for condenser microphones, Push-to-Talk (PTT) priority paging, an optional 2-tone chime, a built-in limiter for overload protection, and bass & treble controls for optimized sound performance.
With its 19-inch, 2U rack-mount design, intuitive front-panel controls, and reliable Class-D performance, the PLE-1ME060-4IN is an ideal choice for schools, offices, hotels, retail stores, factories, warehouses, places of worship, and other commercial PA systems requiring clear announcements and high-quality background music.
Specification
| Details | |
|---|---|
| Model | Bosch PLE-1ME060-4IN |
| Product Type | Class-D Mixer Amplifier |
| Rated Output Power | 60 W |
| Amplifier Type | Class-D |
| Microphone / Line Inputs | 4 × Mic/Line Inputs (Switchable) |
| Music Input | 1 × AUX/BGM Input |
| Built-in Music Source | Bluetooth, USB Media Player & FM Radio |
| Supported Audio Formats | MP3, WAV |
| USB Support | Up to 32 GB |
| Speaker Outputs | 100 V Line & 4 Ω |
| Call-Only Output | Dedicated 100 V Priority Output |
| Frequency Response | 80 Hz – 18 kHz (+1/-3 dB) |
| Total Harmonic Distortion (THD) | <1% @ Rated Output |
| Signal-to-Noise Ratio | ≥70 dB (Line Input) |
| Tone Controls | Bass: ±8 dB, Treble: ±8 dB |
| Phantom Power | Switchable (Mic Inputs) |
| Priority Function | Push-to-Talk (PTT) with Input 1 Priority |
| Chime | Optional 2-Tone Chime |
| Power Supply | 220–230 V AC, 50/60 Hz |
| Speaker Output Connector | Screw Terminal |
| Dimensions (H × W × D) | 100 × 430 × 290 mm (19-inch, 2U Rack Mount) |
| Weight | Approx. 6.5 kg |
| Mounting | Desktop or 19-inch Rack Mount |
| Color | Charcoal |
| Operating Temperature | -10°C to +45°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | <95% |
| Included Accessories | Power Cord, IR Remote Control, User Manual |
