Description
SLA 2104 is a 4 channel, Class H amplifier that delivers 600 watt / channel at 4 Ohm. Detailed specifications are given below
-
SPECIFICATIONS
NO. OF CHANNELS 4 OUTPUT POWER PER CHANNEL 8Ī©: 400W
4Ī©: 600W
8Ī© BRIDGED: 1800WTHD AT RATED POWER 0.1% or less DAMPING FACTOR >300 SIGNAL TO NOISE RATIO (20HZ ~ 20KHZ) 101dB OUTPUT CIRCUITRY AB FREQUENCY RESPONSE 20Hz~20kHz, Ā±0.5dB INPUT CONNECTORS EACH CHANNEL XLR with link OUTPUT CONNECTORS EACH CHANNEL Speakon, 1/4″ and binding post AMPLIFIER AND LOAD PROTECTION Short circuit, output DC, overheat, RF, internal fault, input overload, high frequency overload, mismatched load, mains inrush current FRONT PANEL CONTROLS AND INDICATORS Clip/Protect indicators, 6 step vol control indicator, 21 detent vol level control REAR PANEL CONTROLS 3 DIP switches for stereo, parallel, bridge mode. 2 DIP switches for 0.775V and 1V Sensitivity DIMENSIONS (WXHXD) MM 483 x 457 x 88 NET WEIGHT 23kg AGENCY APPROVALS CE, BIS (IS616:2010)
